High quality hydraulic motors, output shaft bearings which are 50% larger than the nearest competitor’s comparable drive and the use of only high grade materials mean that your Earth Drill will have a long, reliable service life.
High quality hydraulic motors, output shaft bearings which are 50% larger than the nearest competitor’s comparable drive and the use of only high grade materials mean that your Earth Drill will have a long, reliable service life.
Standard with the X1500-X2500 series and unique to Auger Torque, the Non-Dislodgement Shaft is a single piece drive shaft assembled top down and locked into the Earth Drill housing. This design guarantees that the shaft will never fall out, making for a safer work environment, not only for the operator but also any surrounding workers. This is a MUST-HAVE FEATURE for any safety conscious company.
Torque is amplified by using the unique Auger Torque planetary gearbox. This system allows the motors output torque to be multiplied with extreme efficiency as well as ensuring the durability and reliability you need.
Range: 639-2,190 Nm (471-1,615 ft-lb)
Oil Pressure Range: 70-240 Bar (1,015-3,481 psi)
Oil Flow Range: 25-57 lpm (7-15 gpm)
Speed Range: 43-99 rpm
Unit Weight: 47 kg (104 lbs)
Hitch Options: Single Pin Hitch
Double Pin Hitch
Cradle Hitch
Output Shaft Std: 65mm (2.56”) Round
Output Shaft Opt: 2” (50. 8mm) Hex
57mm (2.25”) Square
